Dadi Red Film Faced Plywood

Product Introduction

Red Film Faced Plywood is a multi-layer plywood with unique properties. Made from high-quality wood and bonded under high temperature, it has a stable and durable structure. A red film on its surface greatly improves its weather resistance, wear resistance and water resistance. In the construction field, Red Film Faced Plywood is often used for concrete pouring forms with high appearance requirements, ensuring smooth and flat concrete surfaces. It's also suitable for decoration and modeling projects as a structural support.

Product Advantages

Enhanced Durability

Red Film Faced Plywood is constructed from multiple layers of high-density timber (primarily composed of premium hardwood composite cores) bonded together with high-performance phenolic resin adhesives. With a density ranging from 600 to 700 kg/m³, it far surpasses the density of ordinary plywood. This multilayer composite structure not only boosts the board's overall strength but also effectively distributes stress through staggered grain patterns, significantly reducing the risk of cracking and deformation. As a result, even under lateral pressures as high as 40 kN/m² (well above the 20 kN/m² load limit of regular plywood), Red Film Faced Plywood maintains structural stability, ensuring construction quality and safety.

Excellent Water Resistance

The surface is covered with a 0.4 to 0.6 mm thick red phenolic film, tightly bonded to the substrate through high-temperature, high-pressure processes, creating a seamless waterproof barrier. This film exhibits extremely low water absorption (below 3%, compared to ordinary plywood's usual absorption rate exceeding 10%), maintaining structural integrity even during prolonged immersion tests. Additionally, the phenolic resin itself possesses exceptional water resistance, further elevating the board's waterproof rating.

High Temperature & Chemical Stability

The red phenolic film layer not only effectively blocks moisture but also withstands temperatures up to 130°C without softening or peeling even when briefly exposed to higher temperatures. This high-temperature tolerance allows Red Film Faced Plywood to remain stable during concrete pouring (temperatures can reach over 100°C), preventing dimensional changes due to thermal expansion. Simultaneously, the phenolic resin exhibits good resistance to acids and bases (non-corrosive within a pH range of 3-11), capable of withstanding common chemical exposures on construction sites.

Precision Dimensional Stability & Processing Efficiency

Utilizing advanced numerical control hot-pressing technology, Red Film Faced Plywood boasts thickness tolerances within ±0.2 mm and flatness deviations less than 0.1 mm/m², ensuring perfect fitment in high-precision template assemblies. Standard sizes (such as 1220×2440 mm) facilitate rapid custom cutting, minimizing onsite processing waste and enhancing material utilization by over 20%. Furthermore, the board edges undergo fine treatment, facilitating installation and disassembly, thereby significantly boosting construction efficiency.

FAQs

1. How to handle Red Film Faced Plywood in humid environments?

In humid environments, make sure there's good ventilation around Red Film Faced Plywood. If it gets wet, wipe off the water quickly and let it dry naturally. To prevent moisture damage, consider applying a waterproof coating or sealant before using it in such areas.

2. Can Red Film Faced Plywood be painted over?

Yes, Red Film Faced Plywood can be painted. Before painting, make sure the surface is clean and dry. Use a suitable primer first to improve paint adhesion. Then apply the desired paint color evenly. For best results, follow the paint manufacturer's instructions.

3. What should I do if Red Film Faced Plywood has minor scratches?

For minor scratches on Red Film Faced Plywood, sand the area lightly with fine-grit sandpaper. Be careful not to damage the film too much. After sanding, clean the area and apply a touch-up paint or clear sealant to protect it from further damage.

4. How to cut Red Film Faced Plywood for specific sizes?

Use a sharp circular saw or jigsaw to cut Red Film Faced Plywood. Mark the cutting lines clearly. Make sure the blade is appropriate for plywood. Wear safety gear like goggles and gloves. Cut slowly and steadily for clean edges.

5. Is Red Film Faced Plywood resistant to UV rays?

Red Film Faced Plywood has some UV resistance due to its red film coating. However, prolonged exposure to strong sunlight may still cause fading over time. To enhance its UV resistance, consider applying a UV-protective sealant or keeping it shaded as much as possible.
